Switch Type: Advanced, smart-managed, fixed-configuration Gigabit switches designed for small businesses. Easy-to-deploy, secure and affordable. The first switches with Instant On “anywhere, anytime” configuration and management. Using the Instant On mobile app or the cloud-based web portal, quickly setup, monitor and manage the 1930 switch. Can also choose to manage the device through the local web GUI. This model has 48 10/100/1000 RJ-45 and 4 SFP 1/10GbE ports.
Network Media: Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/ 1000Base-T
Maximum Data Transfer Rate:
125 MB/s
Primary Port Speed: Total non-blocking throughput 70 Gbps
Switching capacity 140 Gbps
Forwarding rate 104.16 Mpps
LEDs: System Status
Ethernet PoE
Speed/ Link/Activity
SFP Speed/Link/Activity
Power: Power method Universal input, 100—240V AC, 50/60 Hz
Power supply AC/DC, internal, 500W
Supported voltage range 100—240V AC
Max. power consumption Excluding PoE output: 64W
Including PoE output: 500W
Total available PoE 500W
